7912B & 7912W LED Flood Single Head w/110 Mot SQR - DISCONTINUED

This light fixture has a Black and White wire with bare striped ends to hook to the Black and White wires in the junction box.  In addition the lamp fixture has a yellow wire that is soldered to the circuit board inside the light housing box.  The yellow wire is not the normal industry standard color coding for a ground wire, (s/b, bare copper, Green, or Green with a Yellow strip).

Because this lamp fixture is a plastic fixture there is a need to ground the circuit board holding the diodes/resisters, this yellow wire is soldered on the circuit board for this grounding purpose.

Yellow Wire/Ground for this model 7912 LED Flood Single Head w/110 mot Sqr
